HARLEY DAVIDSON PARALLEL DIAGNOSTIC SYSTEMS |
To contact us: |
Phone: (847) 651-3099 Fax: (914) 612-8945
MS 5950 | Scanner & Cables Page | Harley Scanner | BMW Scanner | Harley Tuning | Harley Parallel Diagnostics | sitemap |
Designed for professional diagnostics by Harley Davidson & Buell workshops and tuning centers. The Parallel Diagnostic System is designed for measuring input and output signals from the electronic fuel injection module (EFI) and other modules. Measurements can also be made on running engines. The system consists of a set of adapter cables and a breakout box. The breakout box is inserted between EFI module and motorcycle´s wiring harness so that the system continues to function as normal. Monitoring points for all connector pins of the EFI module are clearly arranged on the breakout box. It is possible to measure signals and waveforms from all systems and actuators. Disconnecting the ECU from the breakout box allows quick and reliable check of the integrity of the wiring harness in respect to open circuits and short circuits. With the system connected it allows the operator to test circuitry on running engines. |
MS531-4077 12 & 4 Pin Adapter Harness for TSM, TSSM, HFSM – Delphi Softail till 2010, Dyna till 2011, Sportster till 2013, Touring till 2013, V-ROD |
MS531-4078 18 & 18 Pin Adapter Harness for EFI – Delphi Softail since 2011, Dyna since 2012, Sportster since 2014 |
MS531-4015 35-Pin Adapter Harness for Older Models with Magneti Marelli EFI |
MS531-4064 73-Pin Adapter Harness for Touring EFI Models 2007-2013 |
MS531-4073 36/48 Pin Adapter Harness for BCM (Body Control Module) Softail since 2011, Dyna since 2012, Sportster since 2014, Touring since 2014 |
MS531-4014 36-Pin Adapter Harness for Delphi Models-Softail till 2010, Dyna till 2011, Sportster till 2013, Touring till 2006, V-ROD |
MT535-5130 Universal connector kit includes common adapters (130 Pieces) for non-destructive diagnostic operations on wiring harnesses |
